Similar to illustration

Clamp Assembly Standard Series Size 5 Ø38mm Polyamide W10 Weld Plate Cover Plate, Hex Head Bolt Smooth without Initial Tension

SP-538-PA-H-DP-AS-M-W10

Name: SP-538-PA-H-DP-AS-M-W10
Brand: STAUFF
SKU: SP-538-PA-H-DP-AS-M-W10
Price: 15.6 AUD
Availability: InStock

STAUFF Item No. 1110001060

View Technical Details

Quantity in pieces

price check and stock availability

List price

$15.60 per piece

plus shipping and GST

Add to Enquiry List

Please get in touch with us if you are interested in purchasing our products or looking for an individual quotation based on your product or service requirements.

Technical Details
Bill of materials

STAUFF Online Page-Flip Content

Navigate and search content, forward via email, print, and download in PDF format

Open STAUFF Online Page-Flip Content in New Tab

STAUFF Product Catalogue

Download entire product catalogue

Standard

DIN 3015-1

STAUFF Series

Standard Series

STAUFF Size

Group 5 (DIN 3015 Size 5)

Type of Installation

Single Weld Plate

Mounting & Fitting Combination

Cover plate / Hex. Head Bolt

Installation of Pipes

Installation of Hoses

yes

Installation of Cables

yes

fixed installation of line

sliding installation of line

yes

Vibration Reducing

low

Tension Clearance

Inside Surface

Smooth

for Diameter (mm)

Material (Clamp Body)

PA Polyamide

Material (Weld Plate)

Steel, Phosphated

Material (Cover Plate)

Steel, Zinc-Nickel coated

Material (Bolt)

Steel, Zinc-Nickel coated

Gross Weight

0.199 kg

Customs tariff number

39269097

Packaging unit

25 pieces

The product shown above is a kit consisting of several individual components. ⚠️ It is not always possible to order all individual components of a kit separately in the STAUFF online shop. Below you will find an overview of all purchasable individual components of the kit. Please note: If you order these components individually, please make sure to check that the kit is complete to ensure that it functions properly.
