ISO 7241-1 Series A - Push-to-Connect Couplings - Stainless Steel

Product Description

STAUFF push-to-connect IA series couplings consist of a Female body and a Male tip and ensure assembly of two connecting tube or hose ends can be quickly and easily coupled and uncoupled by hand, without the need of a tool.

Series IA is made according to ISO 7241-1, series A and available in nominal sizes: 06, 10, 12, 19, 25, 38 (1/4”- 1-1/2”)

The proven design is suitable for use in applications with exposure to high moisture environments such as agricultural and forestry machinery. Other applications may, depending on the pressure and flow characteristics, include construction equipment, oil tools, oil equipment, chemical, heavy vehicle wash systems and other demanding industrial hydraulic applications.

Product Features

• Stainless Steel W5 (AISI 316) material for premium anti-corrosion protection
• Poppet valves prevent uncoupled leakage
• Poppet valves open automatically when coupled, within rated working pressure,to keep the flow laminar
• Critical parts are hardened for durability
• Dependable ball-locking mechanism holds the mating halves together
• Socket and plug are precision machined from solid bar stock
• Series IA conforms to the standard of ISO 7241-1 Series A
